Manual, Downloads and Technical details

Manual
Conspit MAX 01 quick guide
Conspit MAX 01 SimHub guide
Conspit MAX 01 function guide


Download
Conspit Link download

Technical details

Product Name: MAX 01
Main Material: Carbon Fiber, Aluminum Alloy
Product Dimensions: 300x170x87 mm
Net Weight: 1400 g (Excluding QR/adapter)
Dashboard: 4.0" 800*480 color display (Compatible with SimHub)
Indicators: 29 x RGB LEDs (15 Rev Lights, 6 Indicators, 8 Multi-functional Indicators)
RGB Buttons: 10 x
Encoder Wheels: 4 x
Rotary Switches: 4 x 12-position
7-way Joysticks: 2 x
Clutch Paddles: 2 x modular Hall sensored clutch paddles
Shift Paddles: Silent magnetic Hall sensored shift paddles
Platform: Windows PC
Connection: USB direct, CONSPIT CAN
Software: SimHub + Conspit Link 2.0

Compatibility

PC only!

SimHub compatible

Conspit wheelbases, or 3rd party wheelbases with supplied 70mm PCD adapter and supplied coiled USB cable.

What is in the package?

1x Conspit Max 01 steering wheel

1x Stickers

1x USB cable

3x hex wrench

6x M5 nuts

6x M5x16 round head hex bolts

9x M5x14 hex head bolts

1x 8mm open-end wrench

What our customers say about this product?

What does the MAX 01 add over the 300 GT?

The flagship touches: a 4.0-inch 800x480 display with native SimHub dashboard support (versus 2.99 inches on the 300 GT), 10 RGB buttons and four 12-position rotary switches instead of 8 and 3, in a carbon-aluminium structure engineered for high-torque direct drive bases at 1,400 g.

Can the display show SimHub dashboards?

Yes - the 4.0-inch 800x480 display is SimHub compatible, so custom dashboards run directly on the wheel; Conspit publishes a dedicated MAX 01 SimHub guide (linked in Technical details). The 29 RGB LEDs are SimHub-driven as well, and input mapping lives in Conspit Link 2.0.

Which wheelbases does the MAX 01 work with?

Conspit ARES bases, or any third-party wheelbase with a standard 70 mm PCD via the supplied Quick-Con adapter and coiled USB cable. For a cable-free connection on Conspit bases, add the CDR Quick Release wheel-side unit. PC only.

Are shifters and clutch paddles included?

Yes - silent magnetic Hall-sensor shift paddles and two modular Hall-sensor dual clutch paddles come as standard, so bite-point launches and clutch mapping work out of the box.

How many inputs does the MAX 01 have?

10 RGB buttons, 4 encoder wheels, four 12-position rotary switches and two 7-way joysticks, plus the paddles - a control density built for endurance racing, where brake bias, TC, ABS and fuel maps all need a dedicated home. Everything maps in Conspit Link 2.0.
